Cisco Meraki Catalyst 48 Port Layer 3 Gigabit Ethernet Managed Switch C9300-48S-M

The Catalyst 9300 Series, including the new Catalyst 9300X models, continues to shape the future with continued innovation that helps you reimagine connections, reinforce security and redefine the experience for your hybrid workforce big and small. With Catalyst 9300 switches, you choose how you want to manage your network – on-premise, virtual or from the cloud.

Cisco Meraki Catalyst 48 Port Layer 3 Gigabit Ethernet Managed Switch C9300-48S-M Features & Specifications:

●     Highest wireless scale for Wi-Fi 6 and 802.11ac Wave 2 access points supported on a single switch with select models.

●     Catalyst 9300 and Catalyst 9300L/LM models are based on the Cisco UADP 2.0 Application-Specific Integrated Circuit (ASIC) with programmable pipeline and micro-engine capabilities, along with template-based, configurable allocation of Layer 2 and Layer 3 forwarding, Access Control Lists (ACLs), and Quality of Service (QoS) entries.

●     Catalyst 9300X models are based on UADP 2.0sec ASIC which adds line rate support for Crypto, including 100G hardware-based IPsec.

●     x86 CPU complex with 8-GB memory, and 16 GB of flash and external USB 3.0 SSD pluggable storage slot (delivering up to 240GB of storage with an option SSD drive) to host containers. C9300X models support 16GB of memory.

●     USB 2.0 slot to load system images and set configurations.

●     Up to 1 TBps of local stackable switching bandwidth with Catalyst 9300X models.

●     Deeper buffer and higher scale model options for rich multi-media content delivery applications.

●     Flexible and dense uplink offerings with 100G, 40G, 25G, Multigigabit, 10G, and 1G as fixed or modular uplinks.

●     Easy transition from 40G to 100G and 10G to 25G with dual-rate optics.
