Bogen Communications Nyquist 4-Channel Audio Power Amplifier NQ-A4060-G2

Bogen's Nyquist-based networked audio power amplifiers offer cost-effective performance for permanent installations and commercial sound, designed to meet the rigorous requirements of today's sophisticated sound systems. Built with the commercial sound contractor in mind, these amplifiers provide exceptional flexibility and versatility without the need for add-on modules, incorporating state-of-the-art, built-in DSP software for comprehensive signal processing, including factory loudspeaker presets that make the amplifier a complete audio solution. Available in 4-channel models with 240, 480, and 1200-watt options, these amplifiers deliver consistent power and performance for applications of any size. Additionally, they utilize advanced Class D amplifier technology for unparalleled sound quality, exceptional reliability, and reduced heat output, enhancing operating efficiency.

Bogen Communications Nyquist 4-Channel Audio Power Amplifier NQ-A4060-G2 Features & Specifications:

• 4 dedicated Balanced Line Inputs (both Phoenix plug & RCA)
• Line Inputs can be routed-out over the Nyquist network
• Network-based audio input (paging, audio distribution)
• 4-ohm, 8-ohm, 25V, and 70V outputs
• GUI based DSP control
• 16-band Graphic Equalizer
• Signal Present and Clip Monitor
• Adjustable High Pass, Low Pass, and Bandpass Filters
• Noise Gate
• Compressor/Limiter
• 7-band Parametric Equalizer
• Switch-selectable 4-Channel (4-ohm/25V), 3-Channel (4-ohm/25V, 8-ohm
• Safety: CAN/CSA 62368-1:2014; EN62368-1:2014
• EMC: FCC Part 15 & ICES-003 Class B, EN 55032 Class B
• 1/2 Rack Width - Wall, Rack, or Shelf mountable – 2RU packages
• 19” Rack Mount Kit (NQ-RMK03 or NQ-RMK04; sold separately)
